EMANON PART NO.
MS16995-11B
MS16995-11B is a screw in steel comp 302 or steel comp 303 or steel comp 304 or steel comp 305 or steel comp 316, oxide finish, 0.112 INCHES diameter and 1/2 length.
Screw
SPECIFICATIONS
KEY DIMENSIONS
DIAMETER0.112 in
LENGTH0.500 in (1/2)
THREAD LENGTHMinimum 0.420 in; maximum 0.500 in
THREAD
THREAD4-40
HEAD & DRIVE
HEADFlat chamfer
HEAD HEIGHTMinimum 0.108 in; maximum 0.112 in
HEAD DIAMETER0.176–0.183 in
WIDTH ACROSS FLATS0.094–0.095 in
MATERIAL & FINISH
MATERIALSteel comp 302 or steel comp 303 or steel comp 304 or steel comp 305 or steel comp 316
MATERIAL SPEC66 — FED STD
FINISHOxide
FINISH SPECMIL-C-13924,CL 4
MECHANICAL
TENSILE STRENGTH80,000 psi
HARDNESS≥80 HRB
STANDARDS & TRACEABILITY
NSN5305-00-421-7919
DOCUMENTS
✓Certificate of Conformance & test reports available for most products (standard cert fees apply)
No drawing on file — request it
Fastener Length: 1/2", Thread: 4-40, Head Width: 3/32", Thread Length: 1/2", flat head, coarse thread, MS16995 series screw
