EMANON PART NO.
MS35307-367
MS35307-367 is a screw in steel, passivate finish, 0.375 INCHES diameter and 2-5/32 length.
Screw
SPECIFICATIONS
KEY DIMENSIONS
DIAMETER0.375 in
LENGTH2.156 in (2-5/32)
THREAD LENGTHMinimum 1.188 in
THREAD
THREAD3/8-16
HEAD & DRIVE
HEADHexagon
HEAD HEIGHTMinimum 0.226 in; maximum 0.243 in
WIDTH ACROSS FLATS0.551–0.562 in
MATERIAL & FINISH
MATERIALSteel
FINISHPassivate
MECHANICAL
TENSILE STRENGTH80,000 psi
HARDNESS≥80 HRB
STANDARDS & TRACEABILITY
NSN5305-00-455-0315
DOCUMENTS
✓Certificate of Conformance & test reports available for most products (standard cert fees apply)
No drawing on file — request it
Fastener Length: 2-5/32", Thread: 3/8-16, Thread Length: 1-3/16", MS35307 series screw
Emanon is a stocking distributor — quality-system certifications are held by the certified manufacturers we source from, not by Emanon. Every shipment carries manufacturer certifications and full lot traceability.
