EMANON PART NO.
MS51958-28
MS51958-28 is a screw in steel comp 302 or steel comp 303 or steel comp 304 or steel comp 305 or steel comp 316, passivate finish, 0.138 INCHES diameter and 0.375 INCHES NOMINAL length.
Screw · listed as MS51958-28 Screw
SPECIFICATIONS
KEY DIMENSIONS
DIAMETER0.138 in
LENGTHNominal 0.375 in
THREAD LENGTHMinimum 0.325 in; maximum 0.375 in
THREAD
THREAD0.138-40 UNF-2A right-hand
HEAD & DRIVE
HEAD HEIGHTMinimum 0.087 in; maximum 0.097 in
HEAD DIAMETER0.256–0.270 in
MATERIAL & FINISH
MATERIALSTEEL COMP 302 OR STEEL COMP 303 OR STEEL COMP 304 OR STEEL COMP 305 OR STEEL COMP 316
FINISHPASSIVATE
MECHANICAL
TENSILE STRENGTH80,000 psi
DOCUMENTS
✓Certificate of Conformance & test reports available for most products (standard cert fees apply)
No drawing on file — request it
Emanon is a stocking distributor — quality-system certifications are held by the certified manufacturers we source from, not by Emanon. Every shipment carries manufacturer certifications and full lot traceability.
