EMANON PART NO.
MS51959-3
MS51959-3 is a screw in steel, passivate finish, 0.086 INCHES diameter and 1/4in length.
Screw
SPECIFICATIONS
KEY DIMENSIONS
DIAMETER0.086 in
LENGTH1/4in
THREAD LENGTHMinimum 0.214 in; maximum 0.250 in
THREAD
THREAD2-56
HEAD & DRIVE
HEADFlat countersunk
HEAD DIAMETER0.147–0.172 in
MATERIAL & FINISH
MATERIALSteel
FINISHPassivate
MECHANICAL
TENSILE STRENGTH80,000 psi
STANDARDS & TRACEABILITY
NSN5305-00-727-8833
DOCUMENTS
✓Certificate of Conformance & test reports available for most products (standard cert fees apply)
No drawing on file — request it
Length: 1/4in., thread: 2-56, flat countersunk head machine screw, corrosion resistant steel, coarse thread.
Emanon is a stocking distributor — quality-system certifications are held by the certified manufacturers we source from, not by Emanon. Every shipment carries manufacturer certifications and full lot traceability.
