EMANON PART NO.
MS51959-31
MS51959-31 is a screw in steel comp 302 or steel comp 303 or steel comp 304 or steel comp 305 or steel comp 316, passivate finish, 0.138 INCHES diameter and 5/8 length.
Screw
SPECIFICATIONS
KEY DIMENSIONS
DIAMETER0.138 in
LENGTH0.625 in (5/8)
THREAD LENGTHMinimum 0.563 in; maximum 0.625 in
THREAD
THREAD6-32
HEAD & DRIVE
HEADFlat countersunk
HEAD DIAMETER0.244–0.279 in
MATERIAL & FINISH
MATERIALSTEEL COMP 302 OR STEEL COMP 303 OR STEEL COMP 304 OR STEEL COMP 305 OR STEEL COMP 316
FINISHPASSIVATE
MECHANICAL
TENSILE STRENGTH80,000 psi
STANDARDS & TRACEABILITY
NSN5305-00-765-4352
DOCUMENTS
✓Certificate of Conformance & test reports available for most products (standard cert fees apply)
No drawing on file — request it
Fastener Length: 5/8", Thread: 6-32, Thread Length: 5/8", MS51959 series screw
Emanon is a stocking distributor — quality-system certifications are held by the certified manufacturers we source from, not by Emanon. Every shipment carries manufacturer certifications and full lot traceability.
