EMANON PART NO.
NAS1102E3-12
NAS1102E3-12 is a screw in iron alloy 660, passivate finish, 0.190 INCHES diameter and 23/32 length.
Screw
SPECIFICATIONS
KEY DIMENSIONS
DIAMETER0.190 in
LENGTH0.719 in (23/32)
THREAD LENGTHMinimum 0.577 in; maximum 0.670 in
THREAD
THREAD10-32
HEAD & DRIVE
HEADFlat countersunk
HEAD DIAMETER0.322–0.385 in
MATERIAL & FINISH
MATERIALIRON ALLOY 660
FINISHPASSIVATE
MECHANICAL
TENSILE STRENGTH160,000 psi
STANDARDS & TRACEABILITY
NSN5305-01-010-3683
GOVERNING STANDARD80205-NAS1102
DOCUMENTS
✓Certificate of Conformance & test reports available for most products (standard cert fees apply)
No drawing on file — request it
Fastener Length: 23/32, Thread: 10-32, Thread Length: 37/64",
Emanon is a stocking distributor — quality-system certifications are held by the certified manufacturers we source from, not by Emanon. Every shipment carries manufacturer certifications and full lot traceability.
