EMANON PART NO.
NAS1149D0363K
NAS1149D0363K is a washer in aluminum alloy 2024 and aluminum alloy 1230 and anodize finish.
Washer
SPECIFICATIONS
KEY DIMENSIONS
INSIDE DIAMETER0.193–0.213 in
OUTSIDE DIAMETER0.433–0.458 in
THICKNESS0.063 in
SHAPE
PERIPHERAL SHAPERound
CENTER HOLE SHAPERound
CROSS-SECTIONAL SHAPERectangular
MATERIAL & FINISH
MATERIALAluminum alloy 2024 and aluminum alloy 1230
MATERIAL SPECQQ-A-250/5, T3 — FED SPEC
FINISHAnodize
FINISH SPECMIL-A-8625, CL2
STANDARDS & TRACEABILITY
NSN5310-01-385-4624
ALTERNATE PART NUMBERSAN960KD10
FLIS · NSN 5310-01-385-4624 · retrieved 2026-08-08
DOCUMENTS
✓Certificate of Conformance & test reports available for most products (standard cert fees apply)
No drawing on file — request it
size: #10, thickness 1/16", aluminum alloy, annodized finish, NAS1149 series washer
Emanon is a stocking distributor — quality-system certifications are held by the certified manufacturers we source from, not by Emanon. Every shipment carries manufacturer certifications and full lot traceability.
