EMANON PART NO.
NAS1149D0663H
NAS1149D0663H is a washer in aluminum alloy 2024 overall and aluminum alloy 1230 overall.
Washer
SPECIFICATIONS
KEY DIMENSIONS
INSIDE DIAMETER0.380–0.400 in
OUTSIDE DIAMETER0.620–0.645 in
THICKNESS0.057–0.069 in
SHAPE
PERIPHERAL SHAPERound
CENTER HOLE SHAPERound
CROSS-SECTIONAL SHAPERectangular
MATERIAL & FINISH
MATERIALAluminum alloy 2024 overall and aluminum alloy 1230 overall
MATERIAL SPECQQ-A-250/5, T3 — FED SPEC
STANDARDS & TRACEABILITY
NSN5310-01-436-0516
ALTERNATE PART NUMBERSAN960D616
FLIS · NSN 5310-01-436-0516 · retrieved 2026-08-08
DOCUMENTS
✓Certificate of Conformance & test reports available for most products (standard cert fees apply)
No drawing on file — request it
size: 3/8", thickness 1/16", aluminum alloy (2024-t3)
Emanon is a stocking distributor — quality-system certifications are held by the certified manufacturers we source from, not by Emanon. Every shipment carries manufacturer certifications and full lot traceability.
