EMANON PART NO.
NAS1149DN332H
NAS1149DN332H is a washer in aluminum alloy 1100 overall and aluminum alloy 3003 overall.
Washer
SPECIFICATIONS
KEY DIMENSIONS
INSIDE DIAMETER0.109 in nom
OUTSIDE DIAMETER0.245–0.270 in
THICKNESS0.028–0.036 in
SHAPE
PERIPHERAL SHAPERound
CENTER HOLE SHAPERound
CROSS-SECTIONAL SHAPERectangular
MATERIAL & FINISH
MATERIALAluminum alloy 1100 overall and aluminum alloy 3003 overall
MATERIAL SPECQQ-A-561 — FED SPEC · QQ-A-359 — FED SPEC
STANDARDS & TRACEABILITY
NSN5310-00-167-0736
FLIS · NSN 5310-00-167-0736 · retrieved 2026-08-08
DOCUMENTS
✓Certificate of Conformance & test reports available for most products (standard cert fees apply)
No drawing on file — request it
size: #3, thickness 1/32", aluminum alloy
