EMANON PART NO.
NAS561C4-15
NAS561C4-15 is a pin in steel comp 410 or steel comp 414 or steel comp 416 or steel comp 420, passivate finish and 0.131 INCHES MINIMUM AND 0.135 INCHES MAXIMUM diameter.
Pin · listed as NAS561C4-15 Pin
SPECIFICATIONS
KEY DIMENSIONS
DIAMETERMinimum 0.131 in; maximum 0.135 in
MATERIAL & FINISH
MATERIALSTEEL COMP 410 OR STEEL COMP 414 OR STEEL COMP 416 OR STEEL COMP 420
FINISHPASSIVATE
MECHANICAL
HARDNESSRockwell c minimum 43.0 and rockwell c maximum 52.0
FLIS · NSN 011806749 · retrieved 2026-09-16
DOCUMENTS
✓Certificate of Conformance & test reports available for most products (standard cert fees apply)
No drawing on file — request it
Emanon is a stocking distributor — quality-system certifications are held by the certified manufacturers we source from, not by Emanon. Every shipment carries manufacturer certifications and full lot traceability.
