EMANON PART NO.
NAS6205-40
NAS6205-40 is a bolt in steel comp e4340 overall or steel comp 8740 overall, cadmium overall and chromate overall finish, 1/4-24 diameter and 2-61/64 length.
Bolt
SPECIFICATIONS
KEY DIMENSIONS
LENGTH2.953 in (2-61/64)
GRIPMinimum 2.490 in; maximum 2.510 in
THREAD
THREAD1/4-24
HEAD & DRIVE
HEADDished hexagon
MATERIAL & FINISH
MATERIALSteel comp e4340 overall or steel comp 8740 overall
FINISHCadmium overall and chromate overall
STANDARDS & TRACEABILITY
NSN5306-01-292-9555
DOCUMENTS
✓Certificate of Conformance & test reports available for most products (standard cert fees apply)
No drawing on file — request it
Fastener Length: 2-61/64", Thread: 1/4-24, Thread Length: 29/64
